Introduction to Modeling in XSI

Easily learn time-saving modeling techniques, a modeling tools overview, and a proven workflow for modeling in XSI. Software required: XSI 4 or higher (XSI 6.5 required for project files).
Course info
Level
Beginner
Updated
Feb 18, 2008
Duration
4h 22m
Table of contents
Introduction and Project Overview
Introduction to Modeling in XSI
Overview of Surface Mesh Geometry 5m Adding Rotoscopes to the XSI Viewports 4m Creating and Optimizing Polygon Geometry 8m Adding Detail to Geometry with the Bevel Tool 8m Using the Add Edge Tool to Split Polygon Components 8m Extruding Polygons to Create a Serrated Saw Blade 8m Using Lattices to Quickly Reshape Geometry 8m Using the Knife Tool to Split Polygons Quickly 9m Building a Phillips-head Screwdriver with the Revolve Function 17m Duplicating and Repurposing Geometry for Efficient Modeling 12m Utilizing Scene Layers to Keep Your Scene Organized 9m Using the Four Sided Command to Create a Knife Blade 9m Bridging and Welding Polygon Edges 13m Trimming and Lofting Geometry to Create the Knife's Keychain Connector 14m Extruding Geometry Along Curves to Create a Corkscrew 14m Using Edge Creasing to Quickly Create Sharp Edges 13m Working with Curves to Create the Magnifying Glass Casing 9m Using the Add/Edit Polygon Tool to Create New Geometry 7m Utilizing Several Tools and Techniques to Create the Can Opener 13m Additional Techniques for Repurposing Geometry (Part 1) 7m Additional Techniques for Repurposing Geometry (Part 2) 16m Extruding the Thumbnail Indentations into the Various Blades 5m Parenting Objects and Cleaning up Your Scene 10m Adjusting Geometry on Various Layers to Assemble Final Knife 6m Utilizing Deformers as a Modeling Aid 10m Extruding Multiple Components to Create the Keychain Loop 9m Bonus: Using Custom Shelves and Toolbars to Store Commonly Used Tools 5m
Description
Course info
Level
Beginner
Updated
Feb 18, 2008
Duration
4h 22m
Description

Easily learn time-saving modeling techniques, a modeling tools overview, and a proven workflow for modeling in XSI. Contains over four hours of project-based training. Great for new and beginning artists. Popular highlights include: Overview of Modeling Tools in XSI; Overview of Geometry Types; Polygon Modeling Workflow; Using Rotoscopes as Modeling Reference; Optimizing Geometry; Mirroring Geometry; Working with Curves, Surfaces, and Trims; Lofting Curves to Create Geometry; Adding Edge Resolution; Scene Organization Techniques; Principles of Creating Clean Topology; Creating Custom Toolbars and Shelves; Edge-loop Selections; Strategically Adding Resolution; Removing Resolution; Merging Multiple Pieces of Geometry; Lofting Surfaces; Bridging and Welding Components; Splitting Parallel Edge-loops; Re-routing Geometry Flow; Generating Symmetrical Geometry; Reusing and Repurposing Geometry; Modeling with Deformers; Extruding Geometry Along Curves; Edge Creasing; Naming and Organizing Assets; Interactively Adding Edges Around Objects; Building High-res Geometry with Low-res Cages. Software required: XSI 4 or higher (XSI 6.5 required for project files).

About the author
About the author

Kyle was one of the first authors for Digital-Tutors (now a Pluralsight company) and has been a part of the team for over 10 years. Kyle began his career in computer graphics education as a college instructor and worked as a Digital-Tutors rendering tutor and curriculum manager since 2002.

More from the author
Maya 2018 Fundamentals
Beginner
11h 23m
Feb 7, 2018
3ds Max 2018 Fundamentals
Beginner
8h 49m
Sep 27, 2017
Introduction to 3ds Max 2015
Beginner
12h 37m
Jun 4, 2014
More courses by Kyle Green
Section Introduction Transcripts
Section Introduction Transcripts

Introduction and Project Overview
