VLAN Operation and Configuration
In this course, we will examine VLANs, VLAN trunks, the layer 3 switch, as well as some common errors one can make while configuring switched networks.
What you'll learn
VLANs are a great concept and are widely used throughout the networking industry. The idea of a VLAN is simply that an administrator has the ability to configure a switch such that there are multiple broadcast domains enabled, and inter-broadcast domain communication is not allowed. Effectively, a VLAN is a broadcast domain. In this course, VLAN Operation and Configuration, you will cover all things VLAN related. First, you will examine VLANs, VLAN trunks, the layer 3 switch. Next, you will set up a problematic network, and make errors during configuration. Finally, you will examine both how the network will behave and how to repair broken networks. After completing this course, you will be ready to segment a network with a single switch using VLANs.
Table of contents
- Introduction 1m
- Demo: Missing VLANs - Configuring Switch 1 and Switch 2 5m
- Demo: Missing VLANs - Configuring the Layer 3 Switch 7m
- Demo: Examining the Issues When There Are Missing VLANs 7m
- Demo: Identifying Where a Misconfigured Trunk Port Is on a Network 7m
- Demo: Changing the SVI State 6m
- Demo: Adding VLAN 30 to Switch 1 and Seeing Potential Issues in Doing So 7m
- Demo: Configuring VLAN 30 on Switch 2 and the Layer 3 Switch 9m
- Demo: Examining Incorrect VLAN Numbers on the Incorrect Interface 6m
- Summary 1m
About the author
Ross has had a diverse career. He has a Structural Engineering degree from Milwaukee School of Engineering, but gave up the career shortly after graduating from college. Beginning in 1997, Ross began officially working in IT, implementing and supporting a paperless work order system for a Natural Gas Utility in Illinois. Since then, Ross has spent his years teaching and managing data networks. Ross spent 7 years at University of Wisconsin Hospitals and Clinics, supporting and managing the large ... more
